Technical Specifications
Wetted Materials: Stainless Steel / PEEK*, Teflon AF®, PVDF, Ceramics, Sapphire, Ruby
Flow Rate: Programmable Micro: 0.001 – 4.000 ml/min Analytical: 0.001 – 10.000 ml/min Semi-Preparative: 0.1 – 40.000 ml/min
Flow Accuracy: ± 1.0 % 1.000 ml / min
Flow Precision: ± 0.1 % RSD 1.000 ml/min
Pressure Range: 0 – 40 MPa (0 – 6000 PSI) Semi-Preparative: 20 MPa (up to 20.000 ml/min); 10 MPa (up to 40.000 ml/min)
Pressure Pulsation: typical < 0.1 MPa or < 1.0 %
Compressibility Compensation: user-adjustable for different solvents
Dimensions: (W x H x D) 396 x 165 x 478 mm
Power Supply: 100 – 250 ~V (47 – 63 Hz)
